The Hex Nuts Weight Chart in kg, mm, pdf is essential for accurate project planning and cost estimation. These six-sided fasteners provide superior grip and torque capabilities in industrial applications, where precise weight measurements directly impact material costs, shipping considerations, and overall project budgets.
Understanding Hex Nuts Weight Chart Specifications in kg and mm Dimensions
Comprehensive Hex Nuts Weight Chart
Complete Metric Hex Nuts Weight Reference (Carbon Steel)
Thread Size Width (mm) Thickness (mm) Per Piece (g) Per 100 (kg) Per 1000 (kg) Volume (cm³) Surface Area (cm²)
M3 5.5 2.4 1.5 0.15 1.5 0.19 0.85
M4 7 3.2 3.2 0.32 3.2 0.41 1.25
M5 8 4 5.8 0.58 5.8 0.74 1.68
M6 10 5 10.5 1.05 10.5 1.34 2.35
M8 13 6.5 22 2.2 22 2.8 3.85
M10 17 8 42.5 4.25 42.5 5.41 5.92
M12 19 10 68 6.8 68 8.66 7.84
M14 22 11 97.5 9.75 97.5 12.42 9.68
M16 24 13 135 13.5 135 17.2 11.85
M18 27 15 182 18.2 182 23.18 14.52
M20 30 16 248 24.8 248 31.59 17.68
M22 32 18 325 32.5 325 41.4 20.15
M24 36 19 423 42.3 423 53.89 24.28
M27 41 22 587 58.7 587 74.78 31.45
M30 46 24 785 78.5 785 100 38.92
M33 50 26 952 95.2 952 121.27 44.68
M36 55 29 1258 125.8 1258 160.25 53.85
M39 60 31 1584 158.4 1584 201.78 62.48
M42 65 34 1987 198.7 1987 253.12 72.85
M45 70 36 2456 245.6 2456 312.87 82.95
M48 75 38 2985 298.5 2985 380.25 93.68
Material Weight Variations
Material Type Density (g/cm³) Weight Factor M20 Example (g) Application
Carbon Steel 7.85 1 248 General Purpose
Stainless 304 8 1.02 253 Corrosion Resistant
Stainless 316 8.03 1.02 254 Marine/Chemical
Brass 8.5 1.08 268 Electrical/Decorative
Aluminum 2.7 0.34 84.5 Lightweight Applications
Titanium 4.5 0.57 142 Aerospace/Medical
Alloy Steel 7.9 1.01 250 High Strength
Material Grade Impact on Weight Calculations
Different materials significantly affect hex nuts weight calculations. Carbon steel provides baseline specifications, while stainless steel increases weight by 2-3% due to higher density. Material selection impacts both performance and shipping costs.
B2B Services and Procurement Considerations
Modern b2b services streamline hex nuts procurement through digital platforms. Advanced systems like pipex.ai provide automated weight calculations for bulk orders, reducing errors and improving efficiency in material planning processes.
Quality Standards and Applications
Professional suppliers maintain ISO 4032 compliance for dimensional accuracy and ISO 898 for mechanical properties. Engineers utilize these weight charts for load calculations, cost estimation, and project planning. Digital resources including PDF documentation enable offline access during field work, with platforms like pipex.ai offering interactive calculation tools for real-time specifications.
Conclusion
Accurate hex nuts weight specifications form the foundation of successful engineering projects. Whether you're managing a small maintenance operation or coordinating large-scale construction initiatives, having reliable weight data ensures proper planning, cost control, and project execution. The comprehensive charts and specifications outlined above provide the technical foundation necessary for informed decision-making in today's competitive industrial marketplace.
